ROW Outward Opening Window with Standard Guardrails and Screens ROW150C

Bucalu established an industry-leading window and door laboratory and testing center. After ten years of relentless effort, our testing center now covers 4,000 square meters, with an investment exceeding 60 million yuan, performing approximately 11,000 tests annually. This has resulted in an extensive database and a wealth of technical expertise.

Product Details

Sealing process: The opening part adopts hidden drainage and has high watertight performance.



Handle configuration: Humanized handle,the handle is the classic S-plus series with a Bucalu family appearance; The handle has undergone extensive ergonomic research, resulting in a more user-friendly design and comfortable use, hidden installation on the side.



Hinge configuration: Quick positioning and installation to prevent falling off.



Lock point configuration: It has a mushroom head-type clamping locking point and locking bracket, multi-point lock position, so that the anti-pry safety ability is upgraded.



Function configuration: Voice control, mobile app remote control, wind and rain sensor control, etc.



Structural configuration: Standard guardrails and screens ensure user safety.

Parameter

Wall thickness of main profile1.8mm
Waterproof performance GB/T 7106Up to Level 6
Wind load resistance performance GB/T 7106Up to 5,000Pa
U value rating GB/T 8484Uw up to 1.6W/m²K



Opening Sash Size & WeightWidth≤750mm,Height≤1,700mm,Weight≤80KG,Frame≤28mm,Panel≤33mm
Air permeability performance GB/T 7106Up to Level 8
Acoustic performance GB/T 8485Rw up to 42dB
